Maximum linearity and inductance symmetry for extended mid-band clarity
Ideal for super light line array applications
The 6NTLW2000 represents the latest 18sound technology for high quality, low distortion applications. The smallest dual gap motor structure of the family uses the same concept to maximize its benefits in terms of thermal dissipation and Bl symmetry to a wide frequency band, making the 6NTLW2000 the perfect component both as a woofer and a midbass. Dual gap motors linearize inductance and the perfect balance we reached between the motor and the ultra linear suspension allows both very high excursion and extreme precision in the mid band with the lowest intermodulation distortion in the professional market. This features, together with its extreme low weight make the 6NTLW2000 the perfect component for highest quality line arrays and multi-way systems.
Specifications
Design
Parameters
Mounting and Shipping Info
Nominal Diameter152 mm ( in)
Nominal Impedance8 Ω
Minimum Impedance5.5 Ω
Nominal Power Handling1320 W
Continuous Power Handling2600 W
Sensitivity393.0 dB
Frequency Range75 - 8000 Hz
Voice Coil Diameter51 mm (2.0 in)
Winding Materialaluminum
Winding Depth14.0 mm (0.55 in)
Magnetic Gap Depth8.5 mm (0.33 in)
Surround ShapeM-roll
Cone ShapeCurvilinear
Magnet MaterialNeo
Woofer Cone TreatmentWeather protected
Recommended Enclosure3.5 dm3 (0.12 ft3)
Recommended Tuning85 Hz
Resonance Frequency86 Hz
Re5.1 Ω
Qes0.38
Qms5.0
Qts0.35
Vas4.6 dm3 (0.16 ft3)
Sd133.0 cm2 (20.62 in2)
η₀0.7 %
Xmax4.9 mm
Xvar7.5 mm
Mms19.0 g
Bl11.6 Txm
Le0.22 mH
EBP226 Hz
Overall Diameter162 mm (6.38 in)
Bolt Circle Diameter170 mm (6.69 in)
Baffle Cutout Diameter148.0 mm (5.83 in)
Depth108 mm (4.25 in)
Flange and Gasket Thickness14 mm (0.55 in)
Net Weight1.2 kg (2.65 lb)
Shipping Weight1.5 kg (3.31 lb)
Shipping Box185x170x85 mm (7.28x6.69x3.35 in)
2 hours test made with continuous pink noise signal within the range Fs-10Fs. Power calculated on rated minimum impedance. Loudspeaker in free air.
Power on Continuous Program is defined as 3 dB greater than the Nominal rating.
Applied RMS Voltage is set to 2.83 V for 8 ohms Nominal Impedance.
