    Características

    • 96.5 dB SPL 1W / 1m average sensitivity
    • 64 mm (2.5 in) Dual voice coil
    • 500 W AES power handling
    • Extremely balanced BL shape for maximum SPL
    • Optimized thermal conductivity
    • Maximum linearity and inductance symmetry for extended mid-band clarity
    • Ideal for two-ways and line array applications
    The 10NTLW2500 represents the latest 18sound technology for high quality, low distortion applications. The Dual Gap technology comes directly from the Tetracoil motor structure and uses the same concept to maximize its benefits in terms of thermal dissipation and Bl symmetry to a wider frequency band, making the 10NTLW2500 the perfect component both as a woofer and a midbass, in a perfect power/weight ratio.

    The brand new 2.5" Neo Dual gap motor linearizes inductance and minimizes heating and power compression thanks to the high coil surface that makes heat exchange twice as efficient than with standard single coil drivers.
    The perfect balance we reached between the motor and the ultra linear M-roll suspension allows both very high excursion and extreme precision in the mid band with the lowest intermodulation distortion in the professional market.

    This features, together with its extreme low weight (only 3.6 Kg) make the 12NTLW2500 the perfect component for highest quality line arrays and two/three way systems, thanks also to its 1000 watts power handling capabilities which put the NTLW2500 above the performances of 3" voice coils traditional speakers.

    Especificación

    Diseño

    Parámetros

    Información de montaje y envío

    • Impedancia nominal4 Ω
    • Impedancia minima3.1 Ω
    • Manejo de potencia nominal500 W
    • Manejo de potencia continua1000 W
    • Sensibilidad96.5 dB
    • Rango de frecuencia55 - 4500 Hz
    • Diámetro de la bobina64 mm (2.5 in)
    • Material de la bobinacopper
    • Profundidad del devanado19.7 mm (0.78 in)
    • profundidad magnética9.0 mm (0.35 in)
    • Recinto recomendado20.0 dm3 (0.71 ft3)
    • Sintonía recomendada68 Hz
    • Frecuencia de resonancia61 Hz
    • Re2.8 Ω
    • Qes0.27
    • Qms16.0
    • Qts0.27
    • Vas22.0 dm3 (0.78 ft3)
    • Sd346.4 cm2 (53.69 in2)
    • η₀1.7 %
    • Xmax7.6 mm
    • Excursión máxima7.4 mm
    • Mms54.0 g
    • Bl14.2 Txm
    • Le0.3 mH
    • EBP225 Hz
    • Diámetro total260 mm (10.24 in)
    • Diámetro de circunferencia de los tornillos245 mm (9.65 in)
    • Diámetro de la perforación en el baffle233.0 mm (9.17 in)
    • Profundidad157 mm (6.18 in)
    • Espesor del reborde y junta9 mm (0.37 in)
    • Peso neto3.1 kg (6.83 lb)
